- Supports IEEE 802.3, IEEE 802.3u and IEEE 802.3X standards
- Supports IEEEB02.3af and IEEE802.3at power supply standards
- Port：1 RJ45 10/100Mbps, 1 BNC
- Supports RG59 coaxial cable: 400m/100Mbps, 800m/10Mbps
- Supports MDI/MDIX self- adaption
- Supports long range power supply transmission via coaxial cable
- Operating temperature: -10℃ to 45℃
| ePOE Transmitter | ePOE Receiver | |
|---|---|---|
| Function Port | 1 10/100Mbps Port + 1 Coaxial cable Port | |
| Transmission Bandwidth | RG59 coaxial cable: 400m/100Mbps, 800m/10Mbps | |
| PoE Protocol | IEEE8023af, IEEE802.3at | |
| Network Standard | IEEE802.3, IEEE802.3u, IEEE802.3x | |
| Dimensions | 80mm x 48mm x 23 mm (3.15" x 1.89" x 0.91") | |
| Weight | 115g | |
| Enclosure | White Polycarbonate | |
| Operating Temperature | -10°C to 45°C (14°F to 113°F) | |
| Operating Humidity | 5 to 95% Not condensing | |
| PoE pin assignment | 12/36, 45/78 | |
| Power Consumption | <2W | |
