- 8MP
- 3840 (H) × 2160 (V)
- 2.8mm Fixed Lens
- 20m IR Distance
- 0.05lux@F1.2(AGC ON),0Lux with IR ON
- TVI/AHD/CVI/CVBS
- Digital WDR
- IP66
- 12v DC
| Model | SRDT8FW |
| Image Sensor | Sensor: SC8238 1/2.7" Progressive CMOS |
| Resolution | 8MP 3840（H）×2160（V) |
| Signal System | PAL/NTSC |
| Frame Rate | TVI: 8MP@15fpsCVI: 8MP@15fpsAHD: 8MP@15fpsCVBS: 960H |
| Min.illumination | 0.05lux@F1.2(AGC ON),0Lux with IR ON |
| Shutter Time | 1/15 s ~ 1/50,000s |
| Lens | 2.8mm Fixed Lens |
| Horizontal Field of View | H.FOV:93° |
| Day & Night | IR Cut Filter |
| IR Cut Filter | YES,850nm |
| Synchronization | Internal synchronization |
| DWDR | Support |
| AGC | Yes |
| Day/Night Mode | EXT/Auto/Color/BW (Black and White) |
| White Balance | Auto/Manual |
| BLC | Support |
| S/N Ratio | 36dB |
| OSD | Support |
| Video Output Termination | 1-channel BNC video output |
| Switch Button | TVI/AHD/CVI/CVBS |
| IP Rating | IP66 |
| Power Supply | 12v |
| Power Consumption | MAX 5W |
| Led | 18pcs (SMD) |
| IR Range | up to 20M |
| Communication | Up the coax, Protocol |
